产品简介
该产品是新宜公司2013年倾力打造的又一重点机型，是针对国外市场研发的又一新产品。可配套YDH-60型全自动高速双头点焊机或YDH-Z型全自动双头点焊机连线生产、实现全线自动化。
Advantages
This production is Shinyi's another highlight machine with enormous efforts to build in 2013. And it's another latest production for overseas market. It can be connected withYDH-60 full-auto high-speed dual-head ear welder or YDH-Z full-auto dual-head ear welder,achieving full production line running automatically.
主要技术参数
Main Technical Parameters
适用罐型：2-5L圆罐
生产速度：60罐/分钟
罐径范围：Φ170-190mm
适用罐高：150-350mm
适用铁线：Φ2.5-3.5mm
适用电源：AC 380V 50Hz
电机功率：10KW
消耗空气：12L/分钟
机器重量：约2吨
整机尺寸（长x宽x高）：3200x2700x 2400mm
Applicable cans:2-5L round cans
Output:60 CPM
Diameter range:Φ170-190mm
Applicable wire:Φ2.5-3.5mm
Applicable height:150-350mm
Power supply:AC 380V 50Hz
Whole power:10KW
Air consumption:12L/min
Weight:App.2T
Dimension(LXWXH):3200x2700x2400mm
